Home Lifting and Handling Machinery Applications Lifting and Handling Machinery

Lifting and Handling Machinery

Flatbed transport vehicle

Open All | Close All

System Solution

Function		Product Model	Docs
Function		Product Model	Docs
Travelling System	Travelling Pump	V40E60/75/100	V40E
	Travelling Motor	M60V85/115	M60V(E)
	Travelling Controller	HLEC6448A	HLEC
Working System	Working Main Pump	HP6V65/76/85	HP6V
	Working Main Valve	HVSP15，EHV18	HVSP , EHV
	Outrigger Valve	EHD08	EHD
	Steering mode switching	DHF	DHF
Controlling System	Integrated Controller	HLEC-C3-7053	HLEC-C
Hydraulic Cylinder	Hydraulic Cylinder	Whole Set of Hydraulic Cylinders

Functional		Product Model	Docs
Functional		Product Model	Docs
Travelling System	Travelling Pump	V40E60/75/100	V40E
	Travelling Motor	M60V85/115	M60V(E)
	Travelling Controller	HLEC6448A	HLEC
Working System	Working Main Pump	HP6V47/65/76	HP6V
	Working Main Valve	EHV09P	EHV
	Steering mode switching	DHF	DHF
Controlling System	Integrated Controller	HLEC-C3-7053	HLEC-C
Hydraulic Cylinder	Hydraulic Cylinder	Whole set of hydraulic cylinders

Functional		Product Model	Docs
Functional		Product Model	Docs
Travelling System	Travelling Pump	V40E60/75/100	V40E
	Travelling Motor	M60V85/115	M60V(E)
	Travelling Valve	HLEC6448A	HLEC
Working System	Working Main Pump	HP6V47/65/76	HP6V
	Working Main Valve	EHV09P	EHV
	Steering mode switching	DHF	DHF
Controlling System	integrated controller	HLEC-C3-7053	HLEC-C
Hydraulic Cylinders	Hydraulic Cylinders	Whole set of hydraulic cylinders

Functional		Product Model	Docs
Functional		Product Model	Docs
Travelling System	Travelling Pump	V40E60/75/100	V40E
	Travelling Motor	M60V85/115	M60V(E)
	Travelling Contoller	HLEC6448A	HLEC
Working System	Working Main Pump	HP6V76	HP6V
	Working Main Valve	HVSP15	HVSP
	Slewing Motor	HRD	HRD
	Outrigger Valve	EHV08	EHV
	Steering mode switching	DHF	DHF
Controlling System	Integrated Controller	HLEC-C3-7053	HLEC-C
Hydraulic Cylinders	Hydraulic Cylinders	Whole Set of Hydraulic Cylinders

Accessory Component

Function		Product Model	Download
Function		Product Model	Download
Travel system	Travel Pump	V40E , V40G	V40E , V40G
Travel system	Travel Motor	M60V(E)	M60V(E)
Function System	Main Control Pump	HP6V76	HP6V
	Main Control Valve	HVSP , EHV	HVSP , EHV
	Outrigger valves	EHV06 , EHD08	EHV , EHD

Product Advantage

- Travel system:

The travel pump uses the closed V40D/E/G high-pressure series, and the travel motor M60V has an optimized rotating balance design, high-speed performance and smooth start-up characteristics;

- Function system:

The pump HP5V+control valve HVSP/EHV can be used in conjunction to achieve precise adjustment of the flow rate and meet the micro-operation requirements of fork-lifting conditions.
